KENWOOD PKT-300 Radio United Radio Communications

Kenwood

PKT-300

Enhanced Features in a Compact Radio

Introducing the PKT-300 portable radio, which comes with enhanced features that are perfect for those who need a lightweight, small, and powerful device. This radio is designed to be easy to use and can enhance work quality, efficiency, and worker well-being. It has a rugged, compact design, making it an ideal choice for fast-paced, customer service-focused retail, hospitality, warehousing, and entertainment venues. The integrated swivel belt clip makes it easy for employees to wear the radio and take advantage of one-touch, instant-on communications. With a robust 2 watts of transmit power, the PKT-300 provides loud and clear KENWOOD quality audio, even in high noise environments. The bright LCD display is easy to read in low light situations. The option to change frequencies or upgrade to 16 channels further extends the versatility of the PKT-300.

Performance Characteristics

Frequency Band:
UHF

Frequency Range:
450-470 MHz

Power Output:
2W

Standard battery chemistry type:

Battery life (based on a 5-5-90 duty cycle):
Approx. 14 hours

Number of Channels/Groups/Zones:
6

Channel spacing:
12.5 / 25 kHz

Physical Characteristics

Dimensions W x H x D (with standard battery)
1.97 x 3.86 x 1.06 in

Weight (with standard battery)
4.87 oz

Keypad / Keys

Display
4-digit 7-segment display LCD screen

User Environment

Operating temperature
-22 F to + 140F

Mil spec
MIL-STD-810 C/D/E/F/G/H

IP Standards

Request A Quote

COMPACT, LIGHTWEIGHT DESIGN & OPERATING EASE
Compact enough to carry anywhere with ease, the PKT-300 has a distinctively ergonomic form that’s easy to hold and operate. It weighs 4.87oz (138 g) with the rechargeable Li-ion battery and control buttons, which are simple to use with PTT, MON, MENU, CALL, UP and DOWN operations.

2 WATTS OF TRANSMIT POWER
Designed to be easy-to-use, the portable has a full 2 Watts of power for clear voice quality in noisy environments, yet it’s extremely lightweight (4.87 oz).

PROGRAMMABLE CHANNELS
Users can modify each of the 6 or 16 preset channels to any of the 99 pre-stored frequencies.4-DIGIT 7-SEGMENT LCD WITH BACKLIGHTING The large 4-digit 7-segment display makes it easy to check on both channel and signaling information. There is also a 3-level icon in the LCD to indicate how much battery power is left.

POWERFUL BATTERY
The 2200 mAh lithium-ion battery lasts through multiple shifts without recharging. Ready to use, right out of the box.

VERSATILITY
Customize your radio beyond the basic menu with programming software that allows full configuration of buttons and options. This enhances usability, compatibility, and reduces operator errors by restricting access.

Brochure

KENWOOD NX-1200AV/1300AU Brochure

Batteries and Charging [+]

	KNB-81L Li-ion Battery Pack (3.6V/2,200mAh) (Same as supplied)
	KSC-35S Rapid Charger (for Li-ion KNB- 45L/69L/82LC)
	KSC-50K Single Unit Charger (Same as supplied)
	KSC-44MLKS AC Adapter (For KSC-50CR multi-unit use, up to 6 units)
	KSC-506K One Piece 6-Unit Charger

Carry Accessories [+]

KBH-21

Belt Clip (Long 1.91 in / 50mm)

KBH-23K

Swivel Belt Clip Holster

Microphones and Audio Accessories [+]

	KEP-2 2.5mm earphone kit for KMC-45 Speaker Mic
	KHS-22A Behind-the-Head Headset with Flexible Boom Mic and In-lin PTT Single Ear Receiver
	KHS-26 Clip Mic w/ Earphone
	KHS-27A D-Ring Ear Hanger w/PTT & Mic
	KHS-31C C-Ring Ear Hanger w/PTT & Mic
	KHS-8BL 2-wire Palm Microphone w/ Earphone
	KHS-9BL 3-wire Palm Microphone w/ Earphone
	KMC-21A Lightweight Compact Speaker Microphone
	KMC-45D MIL-SPEC, IP54/55 Speaker Microphone
